o w n e r ’ s   m a n u a l

o w n e r ’ s   m a n u a l

GOG Paintball USA
100 Station Street
Loyalhanna, PA 15661

While every effort has been made to ensure
that the information contained in this manual
is accurate and complete, no liability can be
accepted for errors or omissions. GOG Paintball

reserves the right to change the specifications of

the eNMEy

TM

 at any time without prior notice.

The latest version of this manual may be
downloaded free of charge at GOGPaintball.com

eNMEy Manual v 1.0   Copyright © 2012, GOG Paintball SA, all
rights reserved. eNMEy, the eNMEy logo, GR33SE and the GOG
logo are trademarks or registered trademarks of GOG Paintball SA.
The eNMEy is covered by one or more of the following U.S. Patents:
5,613,483; 5,881,707; 5,967,133; 6,035,843; 6,474,326; 6,637,421;
7,100,593; 7,603,997; 7,610,908; D535,709; D546,297; D548,201;
D571,415. Additional US and foreign patents pending.

•

THE ENMEY IS NOT A TOY.

•

MISUSE OF THE ENMEY MAY RESULT IN SERIOUS INJURY OR DEATH.

•

EYE PROTECTION SPECIFICALLY DESIGNED FOR PAINTBALL MUST BE
USED IN COMPLIANCE WITH ASTM SPECIFICATION F1776 AND MUST
BE USED BY THE USER AND ANYONE WITHIN RANGE OF THE ENMEY.

•

WEAR EYE PROTECTION DURING DISASSEMBLY OR MAINTENANCE.

•

GOG PAINTBALL RECOMMENDS THAT THE ENMEY ONLY BE SOLD TO
PERSONS 18 AND OLDER.

•

THOROUGHLY READ THE ENMEY MANUAL BEFORE OPERATING.

•

TREAT EVERY PAINTBALL MARKER AS IF IT WERE LOADED.

•

NEVER LOOK DOWN THE BARREL OF A PAINTBALL MARKER.

•

KEEP YOUR FINGER OFF THE TRIGGER UNTIL READY TO SHOOT.

•

NEVER POINT THE ENMEY AT ANYTHING YOU DON’T WISH TO SHOOT.

•

KEEP THE ENMEY ON SAFE UNTIL READY TO SHOOT.

•

KEEP THE BARREL BLOCKING DEVICE ON THE ENMEY’S MUZZLE WHEN
NOT SHOOTING.

•

ALWAYS REMOVE PAINTBALLS AND DEGAS THE ENMEY BEFORE
DISASSEMBLY.

•

STORE AND TRANSPORT THE ENMEY UNLOADED AND DEGASSED IN A
SECURE PLACE.

•

FOLLOW ALL MANUFACTURER’S WARNINGS AND INSTRUCTIONS FOR
PROPELLANT SOURCE HANDLING, STORAGE AND FILLING.

•

DO NOT SHOOT FRAGILE OBJECTS SUCH AS WINDOWS.

•

ALWAYS MEASURE THE VELOCITY OF PAINTBALLS FIRED BY THE
ENMEY BEFORE USE, AND NEVER ADJUST TO FIRE ABOVE 300 FPS
(91.44M/S).

•

PROVIDE THIS MANUAL, OR A COPY WITH THE ENMEY IF GIVEN,
LOANED OR OTHERWISED TRANFERRED TO A NEW OWNER.

m a i n t e n a n c e

m a i n t e n a n c e

D

C

B

A

A

B

C

D

1

2

3

4

5

6

7

8

8

7

6

5

4

3

2

1

E

F

E

F

E

bill_instruc

tion_sheet

_e

xploded

RE

V

bill_instruction_sheet_exploded

SHEET 1 OF 1

UNLESS OTHERWISE SPECIFIED:

SCALE: 1:2

WEIGHT:

REV

DWG.  NO.

E

SIZE

TITLE:

NAME

DATE

COMMENTS:

Q.A.

MFG APPR.

ENG APPR.

CHECKED

DRAWN

FINISH

MATERIAL

INTERPRET GEOMETRIC

TOLERANCING PER:

DIMENSIONS ARE IN INCHES

TOLERANCES:

FRACTIONAL

±

ANGULAR: MACH

±      BEND  ±

TWO PLACE DECIMAL

±

THREE PLACE DECIMAL

±

APPLICATION

USED ON

NEXT ASSY

PROPRIETARY AND CONFIDENTIAL

THE INFORMATION CONTAINED IN THIS

DRAWING IS THE SOLE PROPERTY OF

<INSERT COMPANY NAME HERE>.  ANY

REPRODUCTION IN PART OR AS A WHOLE

WITHOUT THE WRITTEN PERMISSION OF

<INSERT COMPANY NAME HERE> IS

PROHIBITED.

DISASSEMBLY:

 The valve system in the eNMEy

TM

 has only one

major moving part, making it very simple to maintain. This does
not mean it can be ignored. The eNMEy

TM

 should be disassembled

and cleaned when it shows erratic performance, becomes
contaminated with dirt, paint or other debris, or for general
maintenance after 3 or 4 days of use.

•

Unload and de-gas the eNMEy

TM

. Use a 5/16-inch allen wrench to

unscrew and remove the bolt sleeve.

•

Using a soft tool like a wooden chopstick, push the bolt and bolt
stop out the back of the eNMEy

TM

.

•

Clean the interior of the body and all removed parts. Inspect all
o-rings for wear or damage and replace if necessary.

•

Lightly lubricate o-rings with GR33SE

TM

 marker lubricant. Slide

the bolt stop onto the bolt from the rear. Slide the rear of the bolt
into the bolt sleeve and gently screw into the rear of the eNMEy

TM

.

WARRANTY:

  GOG Paintball SA warrants to initial retail purchaser

that the eNMEy

TM

 paintball marker and regulator are free from

defects in materials and workmanship over their operational life.  This

warranty is limited to the repair or replacement of defective parts

with the customer to pay shipping costs. Disposable parts (o-rings,

springs, seals, screws, rubber grips, hoses, tubing, ball detents,

bottom-line ASA, etc.)  are not warranted. This warranty does not

cover surface damage (scratches and nicks), damage resulting from

misuse, improper disassembly and re-assembly or attempts to drill

holes or remove metal or polymer which could degrade performance

and reduce pressure safety factors of the marker.  Do not make

changes to the basic marker parts without written approval.  The only

authorized lubricant for the marker is DOW 33 lubricant (GR33SE

TM

).

Use of any other lubricant may invalidate warranty.  Paintball markers

are non-refundable. This warranty is effective only if the customer

registers the product online at gogpaintball.com within 30 days of

purchase.  This warranty is non-transferrable.  Trigger alteration of

any kind may result in serious injury and may void warranty.

WEIGHT:

OPERATING PRESSURE:

PROPELLANT:

OPERATION:

ANTI CHOP SYSTEM:

BARREL THREAD:

PAINT COMPATIBILITY:

1.65 lbs - 1.86 lbs with barrel

190 psi

CO

2

 or Nitrogen/Compressed air

Low pressure pneumatic

Low-Force bolt

GOG

®

.68 caliber standard paintballs

01 BARREL BLOCKER:

 Screw the barrel into the eNMEy

TM

. Slide

the barrel blocker over the barrel and secure its cord as far back
on the eNMEy

TM

  body  as  possible,  cinching  for  a  tight  fit.  The

barrel blocker is critical safety equipment - nearly as important as
goggles. The barrel blocker must be in use any time the marker
is stored or handled in an area where people or property are not

protected by paintball goggles or paintball field netting.

02 AIR SYSTEM:

 The eNMEy

TM

 is compatible with both CO

2

 and

high pressure compressed air (HPA). Screw in style HPA systems
and CO

2

 tanks can be screwed directly into the Air System Adapter

on the bottom of the eNMEy

TM

 grip frame. For best performance

with CO

2

, use an anti-siphon tank or use a standard tank with

a remote hose. Screw the tank in slowly so that its valve opens
slowly, creating a gentle rise in pressure. NOTE: CO

2

 and HPA

tanks are sold empty and must be filled before use. When using

CO

2

, you may notice occasional bursts of gas released from the

top edge of the regulator. This is the normal function of the relief
valve protecting the eNMEy

TM

 from liquid CO

2

.

D

C

B

A

1

2

3

4

5

6

7

8

E

F

E

RE

V

Barrel_Blocker

SHEET 1 OF 1

UNLESS OTHERWISE SPECIFIED:

SCALE: 1:2

WEIGHT:

REV

DWG.  NO.

E

SIZE

TITLE:

NAME

DATE

COMMENTS:

Q.A.

MFG APPR.

ENG APPR.

CHECKED

DRAWN

FINISH

MATERIAL

INTERPRET GEOMETRIC

TOLERANCING PER:

DIMENSIONS ARE IN INCHES

TOLERANCES:

FRACTIONAL

±

ANGULAR: MACH

±      BEND  ±

TWO PLACE DECIMAL

±

THREE PLACE DECIMAL

±

APPLICATION

USED ON

NEXT ASSY

PROPRIETARY AND CONFIDENTIAL

THE INFORMATION CONTAINED IN THIS

DRAWING IS THE SOLE PROPERTY OF

<INSERT COMPANY NAME HERE>.  ANY

REPRODUCTION IN PART OR AS A WHOLE

WITHOUT THE WRITTEN PERMISSION OF

<INSERT COMPANY NAME HERE> IS

PROHIBITED.

Never use oil or any petroleum based cleaner or lubricant in an
HPA system. Strictly follow manufacturer’s instructions.

03 LOADER/PAINT:

 Insert a paintball loader (not included) into

the eNMEy

TM

 feedneck. High-performance electronic loaders

allow for higher rates of fire and minimal paint breakage. Align the

loader and tighten both its top and bottom clamps with a 7/64-

inch allen wrench. Do not fill the loader with paint until ready to fire
at a paintball field. Use of high-quality, fresh paintballs will result

in best performance.

04 SAFETY:

 The eNMEy

TM

 is equipped with a trigger-block safety.

Pressing the small button on the right side of the grip frame
switches the eNMEy

TM

  to  “live”  for  fire,  exposing  the  red  ring

on the larger button on the left side. Pressing the larger button
blocks the trigger in the “safe” position. Only switch the eNMEy

TM

“live” when in an area that is safe to shoot paintballs. The Safety
should never be considered a replacement for the barrel blocker
or paintball eye protection.

05 VELOCITY:

 At the start

of  each  day’s  use,  the  firing

velocity of the eNMEy

TM

must be calibrated, to
account for variances in
paint and climate. Measuring
and adjusting velocity is a
critical safety procedure to
ensure that the eNMEy

TM

 is

firing  at  safe  levels.  While

wearing ASTM compliant paintball goggles, in an area where

all bystanders are protected, remove the barrel blocker and fire

over a chronograph to measure velocity. Using a 5/32-inch allen

s e t u p

s e t u p

7

6

5

4

3

wrench, adjust the eNMEy

TM

’s vertical regulator for more or less

pressure, to raise or lower velocity. Turning clockwise increases
pressure, to raise velocity, while turning counter-clockwise
decreases pressure to lower velocity. After each adjustment take
2 or three shots to allow the pressure to stabilize, then check

again by firing over the chronograph. Adjust until the eNMEy

TM

 is

firing within limits for the field where you are playing. For safety

reasons and to avoid internal damage, never adjust the eNMEy

TM

to fire at greater than 300 feet per second.

t r o u b l e s h o o t i n g   a n d   s t o r a g e

t r o u b l e s h o o t i n g   a n d   s t o r a g e

DE-GASING:

 Always unload and de-gas the eNMEy

TM

 for transport, storage or maintenance. In an area where it is safe to shoot

and while wearing paintball goggles (the chronograph area at a paintball field is ideal) loosen the eNMEy

TM

’s feedneck and remove

the hopper. Remove the CO

2

 or HPA tank. Fire in a safe direction until all of the gas pressure inside the marker has been released.

WARNING:

If the eNMEy

TM

 is not de-gassed, its regulator may hold enough pressure to fire 3 or more shots, even after the gas supply

has been removed.

TROUBLESHOOTING:

 The most common issues experienced with the eNMEy

TM

 are easily solved.

eNMEy

TM

 is leaking or shows inconsistent velocity:

•

Disassemble and clean the bolt assemnly. Inspect all o-rings
and replace any that show signs of wear or damage. Re-
lubricate with GR33SE

TM

 and reassemble.

•

If using CO

2

, especially in cold weather, an anti-siphon tank,

remote hose or upgrading to a compressed air system may
improve consistency.

•

Use only fresh, good quality .68 caliber paintballs.

eNMEy

TM

 shows inconsistent accuracy:

•

This can be caused by poor quality, out of round paint. Use
high-quality paintballs and store them in a sealed container
in a cool, dry place.

Gas ocasionaly leaks for a moment from regulator or valve:

•

This is a normal venting function that occurs when liquid CO

2

enters the marker (often from pointing downward while shooting)
and protects the low-pressure components from damage.

NOTE:

 The eNMEy

TM

 trigger will only feel responsive when the

marker is charged with gas. Do not pull hard on the trigger with

no gas supply attached, expecting to feel a “click” as excessive

force may cause internal damage.
